Chapter 10 Electrostatics Solutions

Maharashtra State Board 11th Physics Solutions Chapter 10 Electrostatics

1. Choose the correct option.

2. Answer the following questions.

ii. Let q be the magnitude of each charge and 2 be the distance from negative charge to positive charge. Then, the product q(2) is called the dipole moment .

iii. Dipole moment is defined as = q(2)

iv. A dipole moment is a vector whose magnitude is q (2) and the direction is from the negative to the positive charge.

v. The unit of dipole moment is coulomb-metre (C m) or debye (D).

ii. It is the ratio of the force between two point charges placed a certain distance apart in free space or vacuum to the force between the same two point charges when placed at the same distance in the given medium.
i.e., K or ε_r=

iii. It is also called as specific inductive capacity or dielectric constant.

3. Solve numerical examples.

Case II: When square is along XZ plane,
∴ θ = 90°
ø₁= 5 × 10^-2cos 90° = 0 V m

Case III: When normal to the square makes an angle of 45° with the Z axis.
∴ 0 = 45°
∴ ø₃= 5 × 10^-2× cos 45°
= 3.5 × 10^-2V m

11th Physics Digest Chapter 10 Electrostatics Intext Questions and Answers

Can you recall? (Textbookpage no. 188)

Can you tell? (Textbook page no. 189)

i. When a petrol or a diesel tanker is emptied in a tank, it is grounded.
ii. A thick chain hangs from a petrol or a diesel tanker and it is in contact with ground when the tanker is moving.
Answer:
i. When a petrol or a diesel tanker is emptied in a tank, it is grounded so that it has an electrically conductive connection from the petrol or diesel tank to ground (Earth) to allow leakage of static and electrical charges.

ii. Metallic bodies of cars, trucks or any other big vehicles get charged because of friction between them and the air rushing past them. Hence, a thick chain is hanged from a petrol or a diesel tanker to make a contact with ground so that charge produced can leak to the ground through chain.

Can you tell? (Textbook page no. 194)

Three charges, q each, are placed at the vertices of an equilateral triangle. What will be the resultant force on charge q placed at the centroid of the triangle?
Answer:

Since AD. BE and CF meets at O, as centroid of an equilateral triangle.
∴ OA = OB = OC
∴ Let, r = OA = OB = OC
Force acting on point O due to charge on point A,

Force acting on point O due to charge on point B,

Force acting on point O due to charge on point C,

∴ Resultant force acting on point O,
F = _OA+ _OB+ _OC
On resolving _OBand _OC, we get –_OA
i.e., _OB+ _OC= –_OA
∴ = _OA– _OA= 0
Hence, the resultant force on the charge placed at the centroid of the equilateral triangle is zero.

Can you tell? (Textbook page no. 197)

Why a small voltage can produce a reasonably large electric field?
Answer:

Can you tell? (Textbook page no. 198)

Lines of force are imaginary; can they have any practical use?
Answer:
Yes, electric lines of force help us to visualise the nature of electric field in a region.

Can you tell? (Textbook page no. 204)

The surface charge density of Earth is σ = -1.33 nC/m². That is about 8.3 × 10⁹electrons per square metre. If that is the case why don’t we feel it?
Answer:
The Earth along with its atmosphere acts as a neutral system. The atmosphere (ionosphere in particular) has nearly equal and opposite charge.

As a result, there exists a mechanism to replenish electric charges in the form of continual thunderstorms and lightning that occurs in different parts of the globe. This makes average charge on surface of the Earth as zero at any given time instant. Hence, we do not feel it.

Internet my friend (Textbook page no. 205)

i.
ii.
iii.
iv.
[Students are expected to visit the above mentioned websites and collect more information about electrostatics.]
